Industrial Crane Weighing System
Wireless Operation | Flameproof Options | Precision in the Air
Model Series: EWC Crane Scale
Capacity Range: 0.5 MT to 50 MT
Display Type: Jumbo LED / LCD Display
Material Options: Mild Steel, Aluminium Die-Cast, ABS Plastic
Power: Rechargeable Lithium-Ion Battery (11.1V, 5200mAh)
Remote Operation: RF Wireless Remote & Zigbee Display
Key Features
• High-Precision Crane Load Weighing – designed for overhead lifting, crane hooks, and hanging loads
• Rugged Construction – heavy-duty M.S. or aluminum die-cast body, built to withstand industrial shocks
• Wireless Indicator – RF-based remote operation up to 80 meters
• Zigbee Remote Display – line-of-sight visibility up to 1.5 KM
• Long Battery Backup – lithium-ion battery with status indicator and power-saving mode
• Large Display – 100mm Jumbo LED display or 1.8″ FND display for clear visibility
• Bluetooth & Android App Support – easy data syncing, bar code/QR code scanning
• SAP/ERP Integration Ready
• Overload Protection and secure lifting design
• Flameproof version available (optional)
Available Models & Specifications:
| Model | Capacity (MT) | Resolution (Kg) | Repeatability (Kg) | Body Type |
|---|---|---|---|---|
| EWC 500K | 0.5 | 0.1 | 0.2 | ABS Plastic |
| EWC 1T | 1 | 0.2 | 0.5 | Mild Steel |
| EWC 2T | 2 | 0.5 | 1 | Aluminium Die-Cast |
| EWC 3T | 3 | 0.5 | 1 | Aluminium Die-Cast |
| EWC 5T | 5 | 1 | 2 | Aluminium Die-Cast |
| EWC 10T | 10 | 2 | 5 | Aluminium Die-Cast |
| EWC 15T | 15 | 5 | 10 | Mild Steel |
| EWC 20T | 20 | 5 | 15 | Mild Steel |
| EWC 30T | 30 | 10 | 20 | Mild Steel |
| EWC 50T | 50 | 20 | 50 | Mild Steel |
🛈 STC-500K does not support RF remote or rechargeable battery.
🛈 STC-1T has one rechargeable battery, no remote display.
Optional Accessories:
• 58mm Wireless Printer
• IR Remote Control
• Flameproof Housing
• Secondary LED Display
Applications:
Ideal for industries that require elevated load handling with precise weight measurement, such as:
Steel and Foundry Plants
Forging & Heavy Machinery
Warehousing and Logistics
Foundries and Smelters
Ports and Container Yards
Scrap Handling and Recycling
Cement, Chemical, and Refractory Industries
